1.05 Inch IPS TFT LCD Display Module 120x240 4-Wire SPI
This 1.05 inch IPS TFT LCD display module offers 120*240 resolution, 4-Wire SPI interface, 400cd/m² high brightness and full viewing angle. Designed with normally black mode, 262K colors and wide temperature range, it delivers stable performance for wearables, handheld devices, industrial controls, smart home and portable electronics.
Key Specifications
| Product |
1.05 inch IPS TFT LCD Module |
Display Type |
IPS TFT, Normally Black |
| Resolution |
120(RGB)*240(V) Pixels |
Display Colors |
262K Colors |
| Brightness |
400 cd/m² (Typical) |
Outline Dimensions |
14.25*28.60*1.56 mm |
| Viewing Direction |
Full Viewing Angle (ALL) |
Active Area |
11.88*23.76 mm |
| Interface |
4-Wire SPI |
Operating Temperature |
-20℃ to +70℃ |
| Driver IC |
GC9A01 |
Storage Temperature |
-30℃ to +80℃ |
| Pixel Pitch |
0.099*0.099 mm |
Contrast Ratio |
800:1 (Typical) |
| Response Time |
30 ms (Typical) |
Touch Panel |
Without Touch |
| Supply Voltage |
2.5V~3.3V (Typ 2.8V) |
Compliance |
RoHS Compliant |
Product Highlights: 1.05 inch IPS TFT LCD, 120*240 resolution, 4-Wire SPI interface, 400cd/m² high brightness, full viewing angle, 262K colors, wide temperature -20℃~70℃, compact size, RoHS compliant, ideal for wearable & portable devices
Technical Features
- 1.05-inch compact IPS TFT LCD with 120*240 high resolution
- Full viewing angle (ALL directions) for clear image from any angle
- 400cd/m² high brightness for excellent readability in various environments
- 4-Wire SPI interface for stable communication and easy control
- 262K full color display with RGB vertical stripe arrangement
- Normally black display mode with high contrast up to 800:1
- Wide operating temperature range for industrial & outdoor applications
- Ultra-thin module design for easy integration into small devices
- RoHS compliant to meet international environmental standards
- Long-term reliability with strict reliability testing passed
Electrical Specifications
Analog supply voltage VCC: 2.5V ~ 3.3V (Typical 2.8V)
Backlight forward voltage: 2.9V ~ 3.1V (Typical 3.0V)
Backlight forward current: 20mA (Typical)
Input high voltage: ≥0.7*IOVCC; Input low voltage: ≤0.3*IOVCC
Operating current: Stable within rated range for long-term use
ESD protection design to prevent damage from static electricity
Pin Definition
| PIN |
Symbol |
Description |
| 1 |
NC |
No connect |
| 2 |
NC |
No connect |
| 3 |
SDA |
SPI interface input/output pin |
| 4 |
SCL |
Serial interface clock |
| 5 |
D/C |
Display data/command selection pin |
| 6 |
RESX |
This signal will reset the device and it must be applied to properly initialize the chip. -Signal is active low
|
| 7 |
CSX |
Chip selection pin, Low enable. Highdisable. |
| 8 |
GND |
Ground |
| 9 |
NC |
No connect |
| 10 |
VCC |
Power supply for Analog
|
| 11 |
LED-K |
Backlight cathode |
| 12 |
LED-A |
Backlight anode |
| 13 |
GND |
Ground |
Application Scenarios
- Smart wearable devices: smart watches, wristbands, fitness trackers
- Handheld industrial instruments, measuring meters and testing equipment
- Portable electronics: voice recorders, small smart gadgets, beauty devices
- IoT terminals and smart home sensor display modules
- Medical: portable health monitors and small diagnostic devices
- Industrial control: small HMI, equipment status indicators
- Consumer electronics: electronic toys, pedometers, small home appliances
Customization Options
- FPC Design: Custom FPC length, pin layout and interface direction
- Brightness Customization: Adjust brightness level for special environments
- Interface Configuration: SPI timing and driver code adaptation
- Mechanical Adjustment: Outline and installation structure customization
- Packaging Service: Anti-static vacuum packaging with desiccant
- Mass Production Support: Flexible MOQ and lead time for bulk orders
Handling Notes
1. Electrostatic Protection: Use anti-static wrist straps and grounded tools. Avoid dry environment (RH 50%-60% recommended). Do not touch pins or FPC directly with hands.
2. Surface Care: The polarizer is fragile. Use soft cloth with IPA to clean; do not use dry cloth, water or chemical solvents.
3. Storage: Store in dark, anti-static container at 23±5℃, humidity ≤65%RH. Avoid strong light, high temperature and dust.
4. Soldering: Temperature 320~350℃, time ≤10s. Do not stay too long on FPC to avoid burning.
5. Mechanical Safety: Do not press, drop or bend the module. Avoid external force on the display surface.
